2 x 5m Professional Solar Cable and MC4 Coupler (M/FM)

IP67 waterproof MC solar couplers (male and female) each connected to 5m of weather resistant, flexible solar cable.

Current rating of 30 A for Connectors and 55 A for the cable.

Connections are made by crimping and soldering for stability.

The free cable ends of the cable are polarity marked.

A simple and sure solution for the connection of your PV module to a charge controller.

Quantity

Analogue Solar Charge Controller 12 Amp (12 / 24 volt auto select)

An economical and versatile controller for use with one 85 W,  panel (or 2 panels in parallel) and  a 12 volt 55 Ah accumulator, or a 180W 36volt panel and 2 x 12 volt 55 Ah accumulators connected in series.  Maximum input current = 12 A.

It features several protection systems, including battery over discharge protection and high voltage surge protection.

The device will automatically detect a 12 volt or a 24 volt system and adjust accordingly.

Quantity

sc12a = 12 A 12/24 v Auto Select Charge Controller

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units)

Digital Solar Charge Controller 20 Amp (12 / 24 volt auto select)

A sophisticated, but economical, charge controller. It could be used with up to 4 x 180 W panels in parallel, charging 2 x 12 volt, 100Ah accumulators in series. (A 720 W peak power array.)

In addition to all of the protection systems of the model above it has a display screen that can indicate accumulated charge, accumulated discharge or battery capacity.

The device will automatically detect a 12 volt or a 24 volt system and adjust accordingly.

Supplied with user manual.

Quantity

sc20a = 20 A 12/24 v Auto Select Digital Charge Controller

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

£ 12.95   (£ 15.54  Inc. VAT)
More than 10 in Stock
£ 27.52   (£ 33.02  Inc. VAT)
More than 10 in Stock
£ 10.79   (£ 12.95  Inc. VAT)
7 in stock

pvcabc = 2 x 5m PV cable and a pair of couplers

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

Pair of MC4 (M/FM) Locking Cable Couplers

Easy to assemble and can be used with solar cable of 4—6 mm2 conductor cross section.

They have very low contact resistance and they are especially designed for PV installations.

They are IP67 rated when connected and IP2X rated when disconnected.

A data sheet is available from the download section.

Quantity
£ 2.99   (£ 3.59  Inc. VAT)
More than 10 in Stock

mccoup= pair of MC4 couplers

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

Pair of MC4 Branching Connectors

These male and female connectors are used to connect  2 solar PV panels in parallel.

They are compatible with the cable couplers above.

These are useful if you wish to use 2 or more PV panels to charge either a single accumulator or 2 or more accumulators in series.

Data sheet is available in the download section.

Quantity
£ 5.55   (£ 6.66  Inc. VAT)
More than 10 in Stock

pvbrc= pair of MC4 branching connectors

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

Soft Start 600 W Power Inverter  Input 24 volt DC Output 230 volt AC

Modified sine wave, up to 600 W continuous power, up to 1200 W on surge, from 24 v DC.

Battery leads with crocodile clips for temporary connection.

Output 230 volts AC at 50 Hz via BS standard socket output.

Overload, high temperature, short circuit and reverse polarity protected.

Can be used to power a low energy lighting system from 2 x 55Ah accumulators in series and our 180 W PV panel (or 2 x 180 W panels in parallel and 2 x 100Ah accumulators in series).

Quantity
£ 28.95   (£ 34.74  Inc. VAT)
6 in stock

600pinv= 600 W MSW 24 v Input Inverter

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

£ 19.95   (£ 23.94  Inc. VAT)
4 in stock

300pinv= 300 W MSW 12 v Input Inverter

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units.)

Soft Start 300 W Power Inverter: Input 12 volt DC Output 230 volt AC

Modified Sine wave, up to 300 W continuous power, up to 600 W on surge from 12 volts DC.

Battery leads for temporary connection using crocodile clips or cigar lighter adaptor.

Output 230 volts AC at 50 Hz via a BS standard socket and 5 volt DC output via a USB socket.

Overload, high temperature, short circuit and reverse polarity protected.

Ideal to power a low energy lighting system from a solar charged, 55Ah accumulator using our 85 W PV panel.

Quantity
