This robust, compact, weather-proof panel is fitted within an aluminium frame and is ready to mount.

It contains inbuilt blocking diodes and thus it can be used singly, or as a part of an array, in a wide range of applications.

When combined with our 12 Amp solar charge regulator it is ideal for summer charging* of our 12 volt, 55 Ah, long life, deep cycle Gel Battery.

* See note at page bottom

This robust, compact, weather-proof panel is fitted within an aluminium frame and is ready to mount.

It contains inbuilt blocking diodes and thus it can be used singly, or as a part of an array, in a wide range of applications.

A single panel combined with our 12 Amp /24 volt solar charge regulator can summer charge* 2 x 12 volt 55Ah Gel Batteries connected in series.

Delivered to you singly by parcel courier in strong wood packaging, or in multiples, by pallet.

*See note at page bottom

Specifications

Maximum power Pm = 85 W

Optimum power voltage Vmp = 18.7 v

Optimum operating current Imp = 4.55 A

Open circuit voltage Voc = 22.4 v

Short circuit current Isc = 5.23 A

Test conditions  AM 1.5, 1000 W/m2, 25 ± 2 deg C

Number of cells = 36

Temperature range –40deg C to +85deg C

2 Bypass diodes 12 A

Front Cover, High transmission tempered glass 3.2 mm

EVA encapsulated cells

TPT laminate substrate

Frame, Anodized Aluminium Alloy

Hail resistant to 23 m/s, 7.5g

Dimensions: 1210 x 540 x 30 mm

Mass = 8.2 kg

Lifetime: minimum 90% performance at 10 years, 80% at 25 years

Fuse Rating 10 A

With our 5 year Warranty

Specifications

Maximum power Pm = 180 W

Optimum power voltage Vmp = 36.4 v

Optimum operating current Imp = 4.95 A

Open circuit voltage Voc = 43.6 v

Short circuit current Isc = 5.45 A

Test conditions  AM 1.5, 1000 W/m2, 25 ± 2 deg C

Number of cells = 72

Temperature range –40deg C to +85deg C

3 Bypass diodes 12 A

Front Cover, High transmission tempered glass 3.2 mm

EVA encapsulated cells

TPT laminate substrate

Frame, Anodized Aluminium Alloy

Hail resistant to 23 m/s, 7.5g

Dimensions: 1580 x 808 x 35 mm

Mass = 15.5 kg

Lifetime: minimum 90% performance at 10 years, 80% at 25 years

Fuse Rating 10 A

Carries our 5 year Warranty

180 W / 36 volt monocrystalline silicon PV panel:

Sinosola SA 180-72

Certificated* Panel, fabricated to the highest standards using only Grade A cells.

25 year lifetime and guaranteed minimum 90% performance after 10 years.

* view in Download section

Quantity
Quantity

85 W / 18 volt monocrystalline silicon PV module

Sontasun ZTX-M85W

Certificated* Panel, fabricated to the highest standards using only Grade A cells.

25 year lifetime and guaranteed minimum 90% performance after 10 years.

The perfect solution for your caravan, motor home or small boat.

* You can view the Certificate in the Download section.

Charging in summer and winter.

In Northern Europe the solar energy available during the 6 summer months is about 2.5 x the energy available in the 6 winter months. To charge an accumulator in about the same time (say two sunny days) all the year round you would need at least double the panel area for summer use only.

For a 12 v system a single 85 W panel will supply about 15 Ah/day in Summer and 6 Ah/day in Winter.

These amounts scale up accordingly for 2, 3, or 4 panels in parallel.

For a 24 v system a single 180 W panel will provide about 16 Ah/day in Summer and 6.3 Ah/day in Winter.

Further pictures of the panels can be viewed in the Downloads section.

Construction details and further specifications can also be found.

Further pictures of the packaged panels can be viewed in the Downloads section.

Construction details and further specifications can also be found.

Delivered to you singly by parcel courier in strong wood packaging, or in multiples, by pallet.

Modules produced to our exacting specifications by a leading manufacturer.

They carry our brand and 5 year warranty against manufacturing defects.

Similar panels from the same manufacturer are on sale with European brand names for up to 50% more.

Modules produced to our exacting specifications by a leading manufacturer.

They carry our brand and 5 year warranty against manufacturing defects.

Similar panels from the same manufacturer are on sale with European brand names for up to one and a half times the price.

Delivered to you singly by parcel courier in strong packaging with a hardboard insert, or in multiples, by pallet.

£ 99.95   (£ 119.94  Inc. VAT)
More than 10 in Stock
£ 199.95   (£ 239.94  Inc. VAT)
10 in stock

pv180 = 180 W peak Monocrystalline PV Module

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units)

pv85 = 85 W peak Monocrystalline PV Module

Further Details

Discount of 5% on orders of 5 or more

(maximum of 9 units)
